(1) 適用范圍

(1) Applicable scope

①沸石分子篩轉輪濃縮裝置一般適用于風量范圍在5000-200000m3/h(單臺)，VOCs濃度<1500mg/m3的廢氣的治理，并確保轉輪吸附后廢氣達標排放。

① The zeolite molecular sieve rotary concentration device is generally suitable for the treatment of waste gas with an air volume range of 5000-20000m3/h (single unit) and a VOCs concentration of<1500mg/m3, and ensures that the waste gas meets the emission standards after adsorption by the rotary wheel.

②進入沸石分子篩轉輪濃縮裝置的廢氣溫度宜<45℃。

② The exhaust gas temperature entering the zeolite molecular sieve rotary concentration device should be less than 45 ℃.

③進入沸石分子篩轉輪濃縮裝置的廢氣相對濕度<85%。

③ The relative humidity of the exhaust gas entering the zeolite molecular sieve rotary concentration device is less than 85%.

④進入沸石分子篩轉輪濃縮裝置的廢氣中不宜含有粉塵、油煙類物質、高沸點類物質、易發生聚合反應的物質、使分子篩性能退化的酸堿腐蝕性物質等。

④ The exhaust gas entering the zeolite molecular sieve rotary concentration device should not contain dust, oil smoke substances, high boiling point substances, substances that are prone to polymerization reactions, and acid-base corrosive substances that degrade the performance of the molecular sieve.

(2) 性能要求

(2) Performance requirements

①濃縮裝置的沸石分子篩宜采用對揮發性有機物有選擇性吸收的疏水性分子篩，動態吸水率宜<10%。

① The zeolite molecular sieve of the concentration device should be hydrophobic molecular sieve with selective absorption of volatile organic compounds, and the dynamic water absorption rate should be less than 10%.

②沸石分子篩轉輪吸附區表觀流速宜<4.5m/s。

② The apparent flow rate in the adsorption zone of the zeolite molecular sieve impeller should be less than 4.5m/s.

③沸石分子篩轉輪之前廢氣至少要達到F7級過濾，保障進入沸石分子篩轉輪的廢氣中顆粒物含量<1mg/m3。

③ Before the zeolite molecular sieve wheel, the exhaust gas must reach at least F7 level filtration to ensure that the particle content in the exhaust gas entering the zeolite molecular sieve wheel is less than 1mg/m3.

④正常工況下，沸石分子篩轉輪濃縮裝置凈化效率≥90%(濃度越低，凈化效率越難保障)。

④ Under normal operating conditions, the purification efficiency of the zeolite molecular sieve rotary concentration device is ≥ 90% (the lower the concentration, the more difficult it is to ensure the purification efficiency).

⑤沸石分子篩轉輪濃縮裝置的濃縮倍率范圍宜為5-30倍。

⑤ The concentration ratio range of the zeolite molecular sieve rotary concentration device should be 5-30 times.

(3) 設備要求

(3) Equipment requirements

①催化劑使用鉑鈀貴金屬，要求負載量350-850g/m3，空速范圍 16000h-1-25000h-1，處理濃度范圍≤6g，催化床溫度≥300℃，催化劑處理效率≥90%。

① The catalyst uses platinum palladium precious metal, with a required loading capacity of 350-850g/m3, a space velocity range of 16000h-1-25000h-1, a processing concentration range of ≤ 6g, a catalytic bed temperature of ≥ 300 ℃, and a catalyst processing efficiency of ≥ 90%.

②沸石分子篩轉輪吸附濃縮催化燃燒系統具有獨立的PLC控制系統，運行過程中，應具有數據紀錄保存功能，紀錄時間間隔≤1min，保存時間不低于1年。

② The zeolite molecular sieve rotary adsorption concentration catalytic combustion system has an independent PLC control system. During operation, it should have a data recording and storage function, with a recording interval of ≤ 1 minute and a storage time of no less than 1 year.

紀錄參數包括但不限于以下內容：主風機頻率、脫附風機頻率、廢氣溫濕度、冷卻出口溫度、脫附進出口溫度、吸附區壓差、脫附區壓差、過濾裝置壓差、催化劑前后溫度、換熱器前后溫度。

The recorded parameters include but are not limited to the following: main fan frequency, desorption fan frequency, exhaust gas temperature and humidity, cooling outlet temperature, desorption inlet and outlet temperature, adsorption zone pressure difference, desorption zone pressure difference, filtration device pressure difference, temperature before and after catalyst, and temperature before and after heat exchanger.

(4) 安全要求

(4) Safety requirements

①沸石分子篩轉輪濃縮裝置脫附溫度宜在180-220℃，高溫脫附模式沸石分子篩轉輪最高脫附溫度不應超過 300℃。

① The desorption temperature of the zeolite molecular sieve rotary concentration device should be between 180-220 ℃. In the high-temperature desorption mode, the maximum desorption temperature of the zeolite molecular sieve rotary should not exceed 300 ℃.

②沸石分子篩轉輪濃縮后氣體的濃度不得超過爆炸下限的25%。

② The concentration of gas after concentration by the zeolite molecular sieve rotary wheel shall not exceed 25% of the lower explosive limit.

③濃縮裝置安裝區域內應按規定設置消防設施。

③ Fire protection facilities should be installed in the installation area of the concentration device according to regulations.

④沸石分子俯轉輪的沸石分子篩應具有耐高溫及不燃特性。

④ Zeolite molecular sieves with downward rotating wheels should have high temperature resistance and non combustible properties.

⑤沸石分子篩轉輪的沸石分子篩在使用過程中不應脫落，從而影響處理效率。

⑤ The zeolite molecular sieve of the zeolite molecular sieve wheel should not fall off during use, thereby affecting the treatment efficiency.

(5) 運行管理

(5) Operation management

①沸石分子篩轉輪濃縮裝置設施臺賬應紀錄：沸石分子篩轉輪巡檢時間(一周至少巡檢一次)，過濾材料更換時間，密封材料更換時間，催化劑更換時間，沸石分子篩轉輪更換時間以及其他維修記錄。

① The facility ledger of the zeolite molecular sieve rotary concentration device should record: the inspection time of the zeolite molecular sieve rotary wheel (at least once a week), the replacement time of filter materials, sealing materials, catalysts, zeolite molecular sieve rotary wheel, and other maintenance records.

②三方檢測報告中應包含催化燃燒設備進出口濃度和凈化效率。

② The third-party testing report should include the inlet and outlet concentration and purification efficiency of catalytic combustion equipment.

②三方檢測報告中應包含催化燃燒設備進出口濃度和凈化效率。

② The third-party testing report should include the inlet and outlet concentration and purification efficiency of catalytic combustion equipment.
