沸石轉輪+CO設備工作原理 解決企業廢氣達標排放

　　The working principle of zeolite wheel+CO equipment solves the problem of enterprise waste gas emission standards

　　沸石轉輪設備是利用吸附-脫附-濃縮三項連續變溫的吸、脫附程序，使VOCs廢氣通過轉輪的旋轉，同時完成氣體的脫附和轉輪的再生過程。進入濃縮轉輪的有機廢氣經過沸石吸附凈化后直接通過煙囪排放到大氣中。被吸附的有機物質因轉輪的持續轉動(1-6 rad/h)而進入脫附區，利用加熱氣體在此區域脫附，使得低濃度、大風量有機廢氣濃縮為高濃度、小風量的濃縮氣體，進入催化燃燒設備(CO)進行燃燒轉化成二氧化碳及水蒸氣排放至大氣中，如此循環工作。

　　The zeolite rotary equipment utilizes a continuously variable temperature adsorption desorption concentration process to allow VOCs waste gas to pass through the rotation of the rotary wheel, while completing the gas desorption and regeneration process of the rotary wheel. The organic waste gas entering the concentration wheel is purified by zeolite adsorption and directly discharged into the atmosphere through the chimney. The adsorbed organic matter enters the desorption zone due to the continuous rotation of the impeller (1-6 rad/h), and is desorbed in this zone using heated gas. The low concentration, high air volume organic waste gas is concentrated into high concentration, low air volume concentrated gas, which enters the catalytic combustion equipment (CO) for combustion and conversion into carbon dioxide and water vapor, and is discharged into the atmosphere. This cycle works in this way.

　　1、具有極強的吸附能力，可以將多種污染物進行分離，凈化效率高達95%以上，能夠有效去除 VOC （揮發性有機化合物）、重金屬等污染物。

　　1. It has strong adsorption capacity and can separate various pollutants with a purification efficiency of over 95%. It can effectively remove pollutants such as VOCs (volatile organic compounds) and heavy metals.

　　2、具有較強的穩定性和耐久性，可以長期運行，不會出現衰減或失效現象。

　　2. It has strong stability and durability, can operate for a long time, and will not experience attenuation or failure.

　　3、操作簡單，運行成本低，維護方便。只需要定期更換沸石轉輪即可，無需專門安排維護人員進行管理和操作。

　　3. Easy to operate, low operating cost, and convenient maintenance. Just need to replace the zeolite wheel regularly, there is no need to arrange maintenance personnel for management and operation.

　　工藝流程圖

　　Process Flow Diagram

　　1、印刷行業：包括汽車噴涂、板材、鋼鐵制品噴漆過程廢氣，其主要的VOCS為甲苯、二甲苯、酯類、醇類等。

　　1. Printing industry: including exhaust gases from automotive spray painting, sheet metal, and steel product spray painting processes, with the main VOCs being toluene, xylene, esters, alcohols, etc.

　　2、涂覆、上膠：包括磁帶、膠帶生產中的涂覆、上膠過程廢氣，其主要的VOCS為甲苯、酮類、醇類等。

　　2. Coating and gluing: including the waste gas generated during the coating and gluing process in the production of magnetic tapes and adhesive tapes, whose main VOCs are toluene, ketones, alcohols, etc.

　　3、塑料、玻璃鋼加工過程廢氣，其主要的VOCS為苯乙烯、酯類、醇類等。

　　3. The main VOCs in the waste gas generated during the processing of plastics and fiberglass are styrene, esters, alcohols, etc.

　　4、集成電路及液晶顯示器生產中的有機廢氣，其主要VOCS為異丙醇、丙二醇甲醚乙酯、丙酮、二甲亞砜等。

　　4. The main VOCs of organic waste gas in the production of integrated circuits and liquid crystal displays are isopropanol, propylene glycol methyl ether, acetone, dimethyl sulfoxide, etc.

　　5、印刷行業：包括圖書類、食品類、生活用品類等各種包裝材料印刷廢氣，其主要的VOCS為甲苯、異丙醇、乙酸乙酯、甲乙酮等。

　　5. Printing industry: including various packaging materials such as books, food, and daily necessities, the main VOCs of printing waste gas are toluene, isopropanol, ethyl acetate, methyl ethyl ketone, etc.
